Lofrans Windlasses Windlass Vertical, Model 'Sx2', 8mm, 1500w/24v, With Drum
Article number
70728
Description
"Lofrans windlasses Windlass vertical, model "" SX2"", 8mm, 1500W/24V, with drum"
Properties
General
| Articlenumber | 70728 |
Extern
| For | For boats 25-45' (7,5-13m) |
| Motor | 1500W |
| Power Supply | 24V |
| Max. Linear Load | 1500kg |
| Lift Working Load | 175kg |
| Amps Work Load | 75A |
| Line Speed | 19m/min |
| Max. Line Speed | 40m/min |
| Weight | 24kg |
| Control box | Included |
| Size | 8mm |
| Conform | ISO 4565 / DIN 766 |
| Drum | With |
| Weight with drum | 25kg |
Related products
| Product | Properties | Price (ex VAT) | ||
|---|---|---|---|---|
|
70720
|
Articlenumber
70720
For
For boats 25-45' (7,5-13m)
Motor
1000W
Power Supply
12V
Max. Linear Load
1000kg
Lift Working Load
150kg
Amps Work Load
135A
Line Speed
20m/min
Max. Line Speed
40m/min
Weight
19kg
Control box
Included
Size
8mm
Conform
ISO 4565 / DIN 766
Drum
Without
Weight with drum
20kg
|
€ 1.442,99
Stock 1
|
|
|
70725
|
Articlenumber
70725
For
For boats 25-45' (7,5-13m)
Motor
1500W
Power Supply
24V
Max. Linear Load
1500kg
Lift Working Load
175kg
Amps Work Load
75A
Line Speed
19m/min
Max. Line Speed
40m/min
Weight
24kg
Control box
Included
Size
8mm
Conform
ISO 4565 / DIN 766
Drum
With
Weight with drum
25kg
|
€ 1.413,84
Stock 0
|
|
|
70723
|
Articlenumber
70723
For
For boats 25-45' (7,5-13m)
Motor
1000W
Power Supply
12V
Max. Linear Load
1000kg
Lift Working Load
150kg
Amps Work Load
135A
Line Speed
20m/min
Max. Line Speed
40m/min
Weight
19kg
Control box
Included
Size
8mm
Conform
ISO 4565 / DIN 766
Drum
Without
Weight with drum
20kg
|
€ 1.451,58
